The best insulating safety glass for renovation
VACUBEL
THINNER. WARMER. SAFER.
Vacubel is an ultra-thin vacuum glass from just 6.3 mm thick, ideal for the renovation market. Unlike double and triple glazing, vacuum glass is so thin that window frames don't need to be modified. You can simply replace single glazing with Vacubel, improving comfort and significantly reducing energy costs.
Vacubel is standard tempered safety glass (NEN3569) with a safe breakage pattern. It is also available as laminated glass. Three models — Slim, One, and Pascal — cover all needs from maximum insulation to solar protection.
SPECIFICATIONS
THICKNESS from 6.3 mm
U-value 0.4–0.57 W/m²K
SOUND INSULATION 36 dB
WARRANTY 15 years
Vacubel Models
VACUBEL SLIM
U = 0.45
W/m²K
Thickness 6.3 / 8.3 mm
Weight 15 / 20 kg/m²
Max size 1500×2500 mm
Light transmission 70%
Solar factor 39%
Seal color yellow
VACUBEL ONE
U = 0.57
W/m²K
Thickness 8.15 / 10.15 mm
Weight 20 / 25 kg/m²
Max size 1500×2500 mm
Light transmission 68%
Solar factor 58%
Seal color black
VACUBEL PASCAL
U = 0.4
W/m²K
Thickness 8.3 / 10.3 mm
Weight 20 / 25 kg/m²
Max size 1500×2500 mm
Light transmission 78%
Solar factor 40%
Seal color red
VACUUM GLAZING ADVANTAGES
ULTRA-THIN PROFILE
From 6.3 mm — up to 7 times thinner than triple glazing (42 mm). Fits existing frames without modifications.
NOISE REDUCTION
Thanks to the lack of air between the panels, the absorption level reaches 36 dB, corresponding to that of advanced acoustic solutions.
BEST INSULATION
U-value 0.4–0.57 — better than HR++ double (1.1) and comparable to HR+++ triple (0.6) glazing.
ECO-FRIENDLY
Due to its low carbon footprint and 100% recyclability, vacuum glass is ideal for sustainable construction.
SAFETY GLASS
Standard tempered safety glass (NEN3569). Available in Safety (burglar-resistant) and Design (silk-screen edge) variants.
INTERESTED?
Contact us to discuss your project and find the optimal solution.
